RPLIDAR LPX-T1

RPLIDAR LPX-T1
AGV / Multi-point Interactive / AMR

Core Features

Scanning frequency

20Hz

Working Range

0-270°

Scanning Range

0.05-40m

Angular Resolution

0.12°

Types of LIDAR

2D

Overview: LPX-T1

The LPX-T1 is Slamtec’s first medium and long-range high-performance laser LIDAR. With a scanning range of up to 40 meters and a scanning angle of 270 degrees, this device provides enhanced accuracy and precision. It features impressive light resistance up to 80,000 lux and a sampling frequency of up to 60,000 times per second. This enables the generation of real-time point cloud maps, ensuring precise environmental perception and navigation. Tailored specifically for AGV applications, the LPX-T1 also serves well in other scenarios such as service robots and lightweight autonomous vehicles (e.g., parking lot unmanned vehicles). It is an excellent choice for robot localization and mapping needs.

Highlights

Millimeter-Level High-Precision Scanning Performance

The LPX-T1 incorporates advanced DTOF (Direct Time of Flight) laser ranging technology and Slamtec’s high-speed signal solution to deliver real-time, millimeter-level, high-precision distance and location detection. With DTOF technology, the LPX-T1 ensures consistent ranging resolution, maintaining its accuracy even over longer distances. It also enables the detection of a wide variety of objects, including black materials, highly reflective surfaces, and transparent glass. This capability equips robots with precise environmental awareness and localization, ensuring reliable navigation and obstacle avoidance in complex environments.

Extended 40-Meter Detection Range

The LPX-T1 delivers exceptional detection performance, reaching up to 40 meters, enabling precise tracking and identification of objects at long distances. This expanded range enhances the robot’s ability to navigate and avoid obstacles with increased safety and responsiveness. Ideal for various settings, including industrial warehouses, factories, and commercial spaces, it provides superior environmental perception for optimal performance.

270° Broad Scanning Coverage

The LPX-T1 features clockwise rotation ranging, enabling 270-degree laser scanning for precise environmental mapping. From expansive warehouses to compact production lines, the LPX-T1 accurately detects surroundings and generates detailed point cloud maps, offering robots complete and reliable environmental insights for seamless navigation and operation.

Ultra-fast Sampling Capability (60,000 times/second)

The LPX-T1 boasts an enhanced optical design and advanced algorithms, achieving a laser sampling rate of up to 60,000 times per second. This high-speed sampling meets the demands of rapid motion, ensuring real-time environmental data updates. It empowers robots to make quick decisions and precise adjustments, maintaining stability and accuracy even in dynamic, high-speed scenarios.

Precision Detection of Small Objects

Detecting small objects is crucial in AGV applications, and the LPX-T1 excels with an angular resolution of up to 0.12°. This capability enables it to precisely identify fine object details, ensuring accurate recognition of small targets. From navigating obstacles in warehouses to handling narrow pathways and complex environments, the LPX-T1 delivers efficient and reliable detection, empowering AGVs with superior navigation and obstacle avoidance performance.

80,000 Lux Ambient Light Resistance

Equipped with cutting-edge anti-interference technology, the LPX-T1 effectively mitigates disruptions caused by ambient and sunlight exposure. Whether in intricate indoor settings or under intense outdoor lighting, it ensures stable operation and delivers dependable environmental perception, enabling seamless performance across diverse scenarios.

5 Years Long Life With Exclusive OPTMAG Technology

Most traditional non-solid-state LIDARs rely on slip rings for power and data transmission, limiting their lifespan to just a few thousand hours due to mechanical wear. Slamtec has developed OPTMAG technology, a proprietary solution combining wireless power and optical communication. This innovation eliminates the durability issues of conventional systems by preventing electrical connection failures from physical wear, significantly extending the device’s operational life.

Compatible with Multiple Development Platforms

To enhance development efficiency, Slamtec offers the RobotStudio software, a professional tool for LIDAR debugging. Additionally, Slamtec provides SDK development kits compatible with various platforms, including x86 Windows, x86 Linux, and ARM Linux. This ensures seamless integration across a wide range of development applications.

Compliant with CLASS 1 Laser Safety Standard

Using a low-power infrared laser with a modulated pulse design, the LPX-T1 complies with the Class 1 laser safety standard, ensuring it is completely safe for human eyes.
