RPI-CAM-MIPI

The RPi-CAM-MIPI accessory board is a MIPI-CSI camera module adapter, AR0144 CMOS image sensor with ONSEMI IAS interface by default, which features 1/4-inch 1.0 Mp with an active-pixel array of 1280H x 800V. The bypassable on-board ISP chip allows it to be used with a wide range of SoCs. This accessory board connects to the EVK board through the 22P/0.5mm Pitch FPC cable.

Supported Devices

Processors and Microcontrollers

i.MX 9 Processors

• i.MX93: i.MX 93 Applications Processor Family – Arm® Cortex®-A55, ML Acceleration, Power Efficient MPU

Features

AR0144CS 1/4‐inch 1.0 Mp CMOS Digital Image Sensor

• Active Pixels: 1280 (H) × 800 (V)
• Shutter Type: Global Shutter
• Output: MIPI, 1−lane or 2−lane / Parallel 12-bit
• Frame Rate: 720p60
• Operating Temperature: –40°C to + 85°C (Ambient) / –40°C to + 105°C (Junction)

RPI-CAM-MIPI Board

• 22-pin / 0.5mm FPC/FFC connector interface to motherboard
• Pin definition compatible with Raspberry PI Camera interface
• ONSEMI IAS 34-pin board to board connector for image sensor
• Bypassable external ISP ONSEMI AP1302 support
