BEAGL-BONE-AI-64

BeagleBone® AI-64 embedded computing board based on Jacinto™ TDA4VM Arm® Cortex®-72 processor

The BeagleBone® AI-64 from the BeagleBoard.org Foundation is a complete system for developing artificial intelligence (AI) and machine-learning solutions with the convenience and expandability of the BeagleBone platform and onboard peripherals to start learning and building applications.

Using locally hosted, ready-to-use, open-source focused tool chains and development environment, a web browser, power source and network connection are all that is required to start building performance-optimized embedded applications.

Industry-leading expansion possibilities are enabled through familiar BeagleBone cape headers, with hundreds of open-source hardware examples and dozens of embedded expansion options readily available off the shelf.

Features

• Memory
• 4GB double-data-rate 4 (DDR4) RAM
• 16GB embedded MultiMediaCard (eMMC) onboard flash storage
• Processor
• Dual Arm® Cortex®-A72 microprocessor subsystem at 2GHz C7x plus MMA (8 TOPS) and two C66x floating-point very long instruction word (VLIW) digital signal processors (DSPs)
• Three dual Arm Cortex-R5 coprocessors
• Two six-core programmable real-time unit and industrial communication subsystem (PRU-ICSSG)
• PowerVR® Series8 GE8430 3D graphics processing unit (GPU)
• Accelerated video codecs (two 1080p30 H.264 encode, eight 1080p30 H.264/H.265 decode)
• Connectivity
• USB Type-C® for power and superspeed dual-role data
• Two USB superspeed Type-A hosts
• Gigabit Ethernet
• Mini DisplayPort™
• Two four-lane camera serial interface (CSI) and display serial interface (DSI)
• Two 46-pin headers
• M.2 eKey
• Software compatibility: Debian® GNU/Linux
