DFR0849 2-way Fast Charge Buck Module (Compatible with Raspberry Pi 4B & Jetson Nano)

  • Mã sản phẩm: DFR0849 2-way Fast Charge Buck Module
  • Nhà sản xuất: DFRobot
  • Website hỗ trợ: https://www.proe.vn
190.000₫

INTRODUCTION

This 2 USB buck fast-charging module integrates the common 5V charging recognition function, which is compatible with 99% of the mobile phones on the market. Compared with products without charging recognition function, this module can save a lot charging time by triggering the peak current via fast charging protocol. It features 6~32V input and 3~12V output(default 5V). The voltage can be changed through fast-charging decoy. Multiple fast-charging protocols are supported and the 2 channels work independently.

With steady output, this Fast Charge Module is able to work for a long time without voltage shift. It can be suitable for projects like mobile phone fast charging, Car charging retrofit, solar charger, DIY power source, etc.

2-way Fast Charge Buck Module

FEATURES

  • 2-way USB port output
  • Support multiple fast charging protocols
  • Can be used as charging and power supply

SPECIFICATION

  • Input Voltage Range: 6V-32V
  • Output Voltage: 3-12V, automatically adjust according to the fast charge protocol (default output is 5V, input is 2V higher than output)
  • Output Current: 0-3A
  • Output Power: ≤24W (5V@3.4A, 9V@2.5A, 12V@2A, etc.)
  • Chip Protection: input over-voltage and under-voltage protection, input over-current protection, output over-current and short-circuit protection, whole machine over-temperature protection
  • Support Fast Charge Protocol:

               Support DCP protocol, BC1.2, Apple, Samsung protocol

               Support Huawei fast charge protocol FCP/SCP, AFC

               Support Spreadtrum fast charge protocol SFCP

               Support Qualcomm QC2.0 and 3.0

               Support MTKPE1.1/PE2.0

SHIPPING LIST

  • 2-way Fast Charge Buck Module x1
