DCA1000EVM Real-time data-capture adapter for radar sensing evaluation module

Features for the DCA1000EVM

• Supports lab and mobile collection scenarios
• Captures LVDS data from AWR/IWR radar sensors
• Streams output in real time through 1-Gbps Ethernet
• Controlled via onboard switches or GUI/library

Description for the DCA1000EVM

The DCA1000 evaluation module (EVM) provides real-time data capture and streaming for two- and four-lane low-voltage differential signaling (LVDS) traffic from TI AWR and IWR radar sensor EVMs. The data can be streamed out via 1-Gbps Ethernet in real time to a PC running the MMWAVE-STUDIO tool for capture, visualization, and then can be passed to an application of choice for data processing and algorithm development.
