RDK X5 MD Carrier Board

Official D-Robotics RDK X5 MD Carrier Board For RDK X5 Module, Suitable For All Variants Of RDK X5 MD Module

D-Robotics RDK X5 MD Carrier Board

Specifically designed for D-Robotics RDK X5 MD Module

The RDK X5 Carrier Board is a companion board for RDK X5 MD Module, provides rich interfaces including USB 3.0, Ethernet, HDMI, MIPI CSI, MIPI DSI and 40PIN header, etc, facilitates functional verification and development of the module.

Specifications

Specifically designed for RDK X5 Module

Easily expand multiple interfaces, making development more convenient

* for reference only, the RDK X5 Module is NOT included.

What's On Board

1. Type-C 5V Power Port
2. USB 2.0 Configuration Pin
3. USB 2.0 Device Port
4. USB3.0 Host Port × 2
5. USB3.0 Host Port × 2
6. Gigabit Ethernet Port
7. Fan Connector
8. PoE Module Header
9. CAM2 Interface MIPI-CSI (4-lane)
10. CAM1 Interface MIPI-CSI (4-lane)
11. 40 PIN Header
12. RDK X5 Module Socket

13. RTC Battery Header
14. CAN Terminal Resistor Selection
15. CAN Bus Header
16. Function Control IO Header
17. Audio Jack
18. I/O Level Selection
19. MIPI-DSI Interface
20. TF Card Slot
21. HDMI Port
22. Debug Port, USB to UART
23. Sleep Button
24. Power Switch

Supports Connecting with multiple devices

More convenient for users to verify and develop module functions

* for reference only, please refer to the package content for detailed part list.

Product Show

Outline dimensions

Resources & Services

Wiki: www.waveshare.com/wiki/RDK_X5_MD_Carrier_Board

Weight: 0.142 kg

RDK X5 MD Carrier Board x1
