Coral USB Accelerator

  • Mã sản phẩm: Coral USB Accelerator
  • Nhà sản xuất: Coral Google
  • Website hỗ trợ:

The Coral USB Accelerator brings powerful ML inferencing capabilities to existing Linux systems.

Featuring the Edge TPU —  a small ASIC designed and built by Google— the USB Accelerator provides high performance ML inferencing with a low power cost over a USB 3.0 interface. For example, it can execute state-of-the-art mobile vision models such as MobileNet v2 at 100+ fps, in a power efficient manner. This allows you to add fast ML inferencing to your embedded AI devices in a power-efficient and privacy-preserving way.

 Models are developed in TensorFlow Lite and then compiled to run on the USB Accelerator.


Edge TPU key benefits

  • High-speed TensorFlow Lite inferencing
  • Low power
  • Small footprint

 Coral is a division of Google, that helps you build intelligent ideas with our platform for local AI.



  • Google Edge TPU ML accelerator coprocessor
  • USB 3.0 Type-C socket
  • Supports Debian Linux on host CPU
  • Models are built using TensorFlow
  • Fully supports MobileNet and Inception architectures though custom architectures are possible
  • Compatible with Google Cloud



Edge TPU ML accelerator

  • ASIC designed by Google that provides high performance ML inferencing for TensorFlow Lite models

Arm 32-bit Cortex-M0+ Microprocessor (MCU)

  •  Up to 32 MHz max
  • 16 KB Flash memory with ECC
  •  2 KB RAM


  • USB 3.1 (gen 1) port and cable (SuperSpeed, 5Gb/s transfer speed)
  • Included cable is USB Type-C to Type-AU

Local inferencing

Run on-device ML inferencing on the Edge TPU designed by Google.


Works with Debian Linux

Connect to any Linux-based system with an included USB Type-C cable.


Supports TensorFlow lite

No need to build models from the ground up. Tensorflow Lite models can be compiled to run on USB Accelerator.


The Coral USB Accelerator must be connected to a host computer with the following specifications:

Any Linux computer with a USB port

  • Debian 6.0 or higher, or any derivative thereof (such as Ubuntu 10.0+)
  • System architecture of either x86_64 or ARM64 with ARMv8 instruction set

Raspberry Pi is supported

  • Only Raspberry pi <2/3 Model B/B+
  • While USB 3.0 provides the fastest performance Raspberry Pi only supports USB 2.0

Tech Specs

ML accelerator Google Edge TPU coprocessor
Connector USB Type-C* (data/power)
Dimensions 65 mm x 30 mm

* Compatible with Raspberry Pi boards at USB 2.0 speeds only.

Supported Operating Systems

Debian Linux

Supported Frameworks

TensorFlow Lite

Part List

1 x Coral USB Accelerator
