Arducam 13MP Pan Tilt Zoom PTZ Camera for Raspberry Pi 4/3B+/3, IR-Cut Switchable Camera with Metal Base and 2 Digital Servos

B016713MP is discontinued, please check 12MP HQ Version Here: B016712MP.

Item Description

PTZ is an abbreviation for pan, tilt, and zoom and reflects the movement options of the camera, and a pan–tilt–zoom camera (PTZ camera) is a camera that is capable of remote directional and zoom control, so it could move the camera and the lens, and that means a single camera can be used to monitor places that should be covered by multiple ones. You can save a lot of cost and time in purchasing and deploying the camera. What’s more, this kit is based on the IR-CUT switchable 13MP camera to get sharp imaging all day and night.

Specs

Sensor: 13MP AR1335
Pixel Size: 1.1um x 1.1um
Resolution: 4160×3120
Optical Size: 1/3″
Frame Rate: 7fps@4160×3120, 11fps@3264×2448/3840×2160, 24fps@2560×1440, 30fps@1600×1200/1920×1080/640×480/320×240
IR sensitivity: Optional with additional Motorized IR-Cut filter
Focus: Front group – focus, Back group – Zoom
Field of View: 91° – 25° (Horizontal)

Application

This cost-effective and flexible PTZ camera performs better in Day&night vision security camera system, motion detection, wildlife photography and other machine vision projects.

Documentation

Arducam 13MP PTZ Camera Module User Guide

Package

1pcs Arducam PTZ Pan Tilt Zoom Lens for Raspberry Pi, assembled with a 13MP IR-CUT switchable camera board and camera control board.
1pcs 15-Pin FPC Cable (11.8 in/30 cm)
1pcs XH2.54 Jumper wire with 6Pin Female Connector (11.8 in/30 cm)
4pcs copper standoffs for the base

Video

How to Use The Arducam 13MP PTZ Camera Module (Tutorial)

13MP PTZ (Pan-Tilt-Zoom) Camera Module for Raspberry Pi & Jetson Nano/NX (UP to 4K & Night Vision)
