15.6inch QLED Monitor

PACKAGE CONTENT

Weight: 1.733 kg

1. 15.6inch QLED Monitor ×1
2. Mini HDMI to HDMI cable ~1m ×1
3. USB Type-A to Type-C cable ~1m ×1
4. HDMI to Micro HDMI adapter ~1m ×1
5. Triangular stand ×1
6. OPTIONS 12V 1A Power supply ×1

15.6inch QLED Quantum Dot Display, 1920×1080, Optical Bonding Toughened Glass Panel, 100%SRGB, Metal Case, Thin And Light Design

• Size15.6″
• Resolution1920×1080
• Display InterfaceMini HDMI
• Display PanelQLED
• Viewing Angle178°
• Touch TypeCapacitive
• Touch Points10-Point
• Touch PortUSB Type-C
• Touch PanelToughened Glass
• Touch Panel TechOptical Bonding
• OSD MenuBrightness/Contrast
• Audio Output3.5mm Jack
• SoundHi-Fi Speaker
• GamingXbox360/PS4/Switch
• EnclosureAluminum Alloy CNC

Device & System Support

Raspberry Pi

Supports Raspberry Pi OS, 10-point touch, driver free
Supports Ubuntu / Kali / WIN10 IoT, single point touch, driver free
Supports Retropie, driver free

Supports all versions of Raspberry Pi

Jetson Nano

Supports Ubuntu, single point touch, driver free

VisionFive2

Supports Debian, single point touch, driver free

PC

Supports Windows 11 / 10 / 8.1 / 8 / 7, 10-point touch, driver free

Game Console

Xbox360, Switch...

Connection Examples

Working With Raspberry Pi 4B

Working With Raspberry Pi 3B+

Working With Raspberry Pi Zero 2 W

You need to prepare additional mini HDMI adapter and USB cable

Working With Jetson Nano

Working With PC

• for reference only, the above controller boards or hosts are NOT included

IPS Display Panel

Excellent Display Performance With 178° Wide Viewing Angle

QLED Quantum Dot Technology

Wider Color Gamut

With 100% NTSC, 100% SRGB, 99% Adobe RGB And 97% DCI-P3 Color Gamut Coverage
Brighter, Clearer And More Natural Color

More Pure Chroma

Chroma Of QLED Increases 58.3%, Makes The Color More Pure, More Vivid

Longer Lifetime

Due To Its Inorganic Characteristic, The Color Life Of QLED Could Be Up To 60000 Hours Without Color Degradation

Thin And Light Body, Exquisite Craftsmanship

Rounded Edge Design, Comfortable Handheld Experience, With Exquisite Details

Capacitive 10-Point Touch

1. up to 10-point touch, depending on the operating system
2. up to 6H hardness toughened glass panel
3. Optical Bonding, display well and dustproof

Enjoy Gaming

Dual-Track Speaker

Ferrite Hi-Fi Speaker, Larger Volume, Wider Sound Range, Better Sound Quality

Interface Introduction

Product Show

Dimensions

Support Touch Screen Customization

Support The Following Ways To Customize The Touch Screen Display In Bulk Order

Over A Decade
Waveshare Grows With Display

* Waveshare has been focusing on display design for over 10 years.

Resources & Services

Wiki: www.waveshare.com/wiki/15.6inch_QLED_Monitor
