• Mã sản phẩm: STM32F4DIS-EXT STM32F4DISCOVERY Extension Board
  • Nhà sản xuất: STMicroelectronics
  • Website hỗ trợ:

This set of 4 boards expands the functionality of the STM32F4 Discovery kit. A base board, connected to the STM32F4 Discovery provides Ethernet connectivity, a micro SD Card™ slot and extension connectors for the LCD and camera boards, and provides easy access to features such as UART, SPI, CAN and so on. The Wi-Fi board connects to the STM32F4 Discovery using serial host interface (UART or SPI). A digital camera board featuring a 1.3 Megapixel CMOS sensor, a 3"5 LCD board with touch screen capability connected to the base board along with a Wi-Fi board featuring the SN8200 Wi-Fi module form a complete system.

For more information, visit

Key Features

  • Base board
    • Micro SD Card™ slot
    • 10/100 Ethernet with IEEE 1588v2 (RJ45 connector)
    • Connector for camera board
    • Connector for LCD board
    • Connector with UART, I2C, SPI, CAN, PWM and GPIOs
  • 3"5 LCD board
    • Driving IC: SSD2119
    • Display format: 320 * 240
    • Color: 262K colors
    • Backlight: PWM control
    • Interface: 16-bit 8080 parallel system interface
    • Touch screen: 4-wire resistive touch screen
  • Camera board
    • Signal system: CMOS 1.3 Megapixel
    • Resolution: Up to 1280 * 1024
    • Supports still photos
    • Frame rate: 15 fps for SXGA, 30 fps for VGA and CIF.
  • Wi-Fi board
    • 2.4GHz IEEE 802.11b/g/n
    • Support AP/STA Dual mode
    • Built-in TCP/IP Stack, HTTP, DHCP, DNS and Web Server
    • Support WPA/WPA2 PSK security
    • Wi-Fi SN8200 module: chipset: Broadcom BCM43362 and STM32
    • Host Interface: UART, SPI Interface & Standalone
    • Other Interface: GPIO, ADC, DAC, I2C
    • JTAG Interface for Debugging
    • Power Options:- 5V Power Jack- Mini USB Plug
