KIT-CRD-8FF65P Silicon Carbide Test/Evaluation Products

This evaluation board demonstrates the switching and thermal performance of 650V SiC C3M MOSFET in a 7-pin D2PAK (TO-263-7L) configured in a half bridge topology. The board is designed for characterizing E_ON and E_OFF losses and steady state thermal performance in SiC MOSFETs. The PCB contains AlN inserts under the MOSFETs to provide electrical isolation and optimized heat transfer to the heat sink.

This design:

• Demonstrates use of an AlN inlay PCB for thermal management of surface mount power devices
• Serves as a PCB layout example for driving D2PAK SiC MOSFETs

Specifications

• Max DC Bus Voltage of 450V
• Max Power of 4.2kW @ 100kHz
• Optimized locations for scope probe measurements of drain current, V_GS, and V_ds
• Predrilled thermocouple locations in the heat sink under the MOSFET
• Synchronous and asynchronous buck and boost topologies supported
• Kit includes two SMA and BNC adapters for measuring V_GS waveforms
• Includes heatsink, fan, fan guard, and thermal pads
• Can be configured as full bridge DC/DC by using two evaluation boards

Applications

• Industrial Power Supplies
• Server/Telecom
• EV-Charging Systems
• Energy Storage Systems (ESS)
• Uninterruptible Power Supplies (UPS)
