HDMI-EXTENDER-KIT

  • Mã sản phẩm: HDMI-EXTENDER-KIT
  • Nhà sản xuất: Waveshare
  • Website hỗ trợ: https://www.proe.vn
600.000₫
PACKAGE CONTENT

Weight: 0.035 kg

HDMI-EXTENDER-KIT x1

HDMI Signal Extender, 1080P High-Definition & Lossless Transmission, Transmission Distance Up To 50m Via CAT-5E/6 Network Cable

HDMI Signal Extender

Transmission Distance Up To 50m Via Network Cable, High-Definition & Lossless



Specifications

TRANSMISSION STANDARD HDMI1.4B
VIDEO INPUT 1080p/1080i/720p/576p/576i/480p/480i
SIGNAL TRANSMISSION Supports using CAT-5E/6 network cable (CAT-6 recommended) instead of HDMI cable, the distance between transmitter and receiver up to 50m
POWER INPUT Type-C port (DC 5V 1A)
APPLICABLE SCENARIOS Security monitoring, Video conference, Multimedia teaching, Home theater, etc.



Connection Example

  • for reference only, the HDMI cables, network cable, and power supply are not included.
  • The RJ45 port on both boards uses a private protocol, and cannot be connected to a switch or router in between.

Supports 1080P HD Quality Transmission

Clearer & Smoother Image, With No Delay In Sound

Note: The quality of the network cable will affect the signal transmission quality, it is recommended to use CAT-6 network cable for better transmission.



Onboard Interface

Applicable Scenarios

Product Show

Outline Dimensions

Resources & Services

Wiki: www.waveshare.com/wiki/HDMI-EXTENDER-KIT
