Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 1x RJ45, 3x USB 2.0

  • Mã sản phẩm: ETH-USB-HUB-BOX
  • Nhà sản xuất: Waveshare
  • Website hỗ trợ: https://www.proe.vn
440.000₫
PACKAGE CONTENT

Weight: 0.06 kg

  1. ETH/USB HUB HAT (B) x1
  2. ABS case x1
  3. Rubber feet 4PCS x1
  4. Screws pack x1
  5. Screwdriver x1

Ethernet / USB HUB BOX For Raspberry Pi Zero Series, 1x RJ45 Ethernet Port, 3x USB 2.0 Ports

Ethernet / USB HUB BOX For Zero

Dull polish surface, well designed, nice & dust-proof

1x RJ45 Ethernet Port | 3x USB 2.0 Ports

Features At A Glance

The ETH-USB-HUB-BOX is a HUB kit with ETH/USB HUB HAT (B) inside. It is tailored for Raspberry Pi Zero series, small in size, each cut-out of the case is exactly aligned with the connector. The case adopts classic Raspberry Pi red/white color combination, with quality dull polish surface, effectively keeping the Zero away from dust. This HUB BOX will provide RJ45 Ethernet port and more USB capability for your Zero, make it easy to connect the Internet and sorts of USB devices.

  • Designed for Raspberry Pi Zero, compatible with Zero series boards
  • 3x extended USB ports, compatible with USB 2.0 / 1.1
  • Incorporates RTL8152B Ethernet chip, supports 1x RJ45 Ethernet port, 10/100M auto-negotiation
  • Pogo pin design, for direct connecting with Raspberry Pi Zero/Zero W/Zero WH
  • Angle rounded design, smooth hand feeling, "simple snap" case lid
  • Quality ABS material, dull polish surface, anti-fingerprint
  • Comes with two different lids, changing as you like

Compatible With Raspberry Pi Series

Specialized Pogo Pin Connection, Dedicated Cut-Outs For Zero Series, Plug-And-Play



Extended Ports

1x RJ45 Ethernet Port, 10/100M Auto-Negotiation
3x USB 2.0 Ports, Compatible With USB 2.0 / 1.1

Two Different Lids, Changing As You Like

"Simple Snap" Design, Easy To Change, Allows Attaching Other Zero HATs

Application Example

Raspberry Pi Zero is NOT included.

Outline Dimensions



Resources & Services

Wiki: ETH/USB_HUB_HAT_(B)
