B-CAMS-IMX

B-CAMS-IMX
Camera module bundle for STM32 boards

Description

The B-CAMS-IMX camera module provides a compelling hardware set to handle multiple computer vision scenarios and use cases. It features a high-resolution 5‑Mpx RGB CMOS image sensor, an inertial motion unit, and a Time‑of‑Flight sensor. It can be used with any STM32 boards featuring a MIPI CSI-2^® interface with a 22‑pin FFC connector to enable full-featured computer vision on STM32 microcontrollers and microprocessors easily.

All features

• Camera module accessory board (MB1854) including:
  • Dual-lane MIPI CSI-2^® data output supporting Sony 5‑Mpx RGB CMOS image sensor
  • M12 × 0.5 lens holder for a variety of commercially available, ready‑to‑use M12 lenses
  • Supplied M12 lens: Manual focus, 87° FOV
  • Inertial motion unit
  • Multizone direct Time‑of‑Flight sensor
  • 3.3 V power
  • Board connector:
    • 0.5 mm‑pitch, 22‑pin flexible flat cable (FFC) connector
  • 22‑pin flexible flat cable
