ESP-C3-32S-Kit ESP32 WiFi+Bluetooth Development Board, Based On ESP32-C3

ESP-C3-32S-Kit ESP32 WiFi+Bluetooth Development Board, Based On ESP32-C3

Overview

This is an entry-level development board based on Espressif ESP32-C3 SoC, which is equipped with a RISC-V 32-bit single-core processor, operating frequency up to 160 MHz, supports secondary development without using other microcontrollers or processors. The ESP32-C3 is an highly integrated low power Wi-Fi and Bluetooth system-level chip (SoC), designed for various applications such as internet of things (IoT), mobile devices, wearable electronics, smart home, etc.

Features

• Onboard ESP-C3-32S module that comes with a PCB antenna
• Onboard CH340, USB to UART converter
• RGB 3-in-1 LED, convenient for secondary development
• USB port for power input, firmware programming, or UART debugging
• 2x15pin extension headers, breakout all the I/O pins of the module
• 2x keys, used as reset or user-defined

Specifications

• Complete Wi-Fi 802.11b/g/n, 1T1R mode data rate up to 150Mbps
• Support BLE5.0 and rate support: 125Kbps, 500Kbps, 1Mbps,2Mbps
• Onboard ESP32-C3 chip, 32-bit RISC-V single-core processor, supports a clock frequency of up to 160 MHz, with 400 KB SRAM, 384 KB ROM, 8KB RTC SRAM
• Support UART/PWM/GPIO/ADC/I2C/I2S interface, temperature sensor, pulse counter
• SMD-38 package
• Integrated Wi-Fi MAC/ BB/RF/PA/LNA/BLE
• Support multiple sleep modes, deep sleep electric current is less than 5uA
• UART rate up to 5Mbps
• Support STA/AP/STA+AP mode and mix mode
• Support Smart Config (APP)/AirKiss (WeChat) of Android and IOS One-click network configuration
• Support UART port local upgrade and remote firmware upgrade (FOTA)
• General AT commands can be better understand
• Support secondary development, integrated Linux development environment
• ESP-C3-32S module acquiesce in using the built-in 4MByte Flash, meanwhile support external Flash version

Applications

The ESP-C3-32S-Kit suit for IoT applications such as:

• Smart home
• Intelligent building
• Industrial automation
• Wearable devices
• IP camera
• Intelligent agriculture

Development Resources

Wiki : ESP-C3-32S-Kit
