Astra 2

  • Mã sản phẩm: Astra 2
  • Nhà sản xuất: Orbbec3d
  • Website hỗ trợ: https://www.proe.vn
19.900.000₫

The Astra 2 is the flagship model of the Orbbec Astra Series, leveraging structured light technology. It is equipped with Orbbec's custom ASIC MX6600, delivering high-quality depth processing. The Astra 2 retains the FoV and depth measurement range of its predecessors while featuring a fully upgraded optical system that enhances measurement accuracy and stability. Additionally, it supports multi-camera synchronization to prevent interference when multiple cameras are used simultaneously.

Astra 2

● High quality depth data output from 0.6m to 8m

● Up to 30 fps at 1600X1200 depth resolution

● Up to 30 fps at 1920X1080 RGB resolution

● Multi-camera synchronization supported

● IMU supported



Operating EnvironmentIndoor / Semi-outdoor

Depth TechnologyStructured Light

Depth Range0.6m - 8m

Ideal Range0.6m - 5m

IMUSupported

Camera DriverUSB 3.0 & USB 2.0

SDKOrbbec SDK

Baseline75mm

Spatial Precision≤0.16%(1600 x 1200 @ 1m & 81% ROI); ≤0.3% (1600 x 1200 @ 2m & 81% ROI)

Depth FoV58° x 45°

Depth Resolution and Frame RateUp to :1600x1200@30fps

Depth Shutter TypeGlobal Shutter

RGB FoV75°x 46°

RGB Resolution and Frame RateUp to :1920x1080@30 fps

RGB Shutter TypeRolling Shutter

Power supplyDC 5V & ≥1.5A

Power Consumption≤3.0W

ConnectorUSB Type-C

Multi-device Sync port8-pin

Operating Temperature0℃ - 35℃

Weight195g / 240g (with mounting base)

Dimensions (W*H*D)144.5 x 34.6 x 35.8 mm / 144.5 x 45.3 x 38.6 mm (with mounting base)

InstallationBottom
