General Information |
|
Order Number |
105393 |
|
Product Line |
ace Classic |
|
Price |
For pricing, please use the request cart to get a quote. |
|
Shipment |
For information about shipping please use the request cart. |
Sensor |
|
Sensor Vendor |
ON Semiconductor |
|
Sensor |
MT9P031 |
|
Shutter |
Rolling Shutter |
|
Max. Image Circle |
1/2.5" |
|
Sensor Type |
CMOS |
|
Sensor Size |
5.7 mm x 4.3 mm |
|
Resolution (HxV) |
2590 px x 1942 px |
|
Resolution |
5 MP |
|
Pixel Size (H x V) |
2.2 µm x 2.2 µm |
|
Frame Rate |
14 fps |
|
Mono/Color |
Color |
EMVA Data |
|
EMVA Quantum Efficiency - blue (typical) |
7.2 % |
|
EMVA Quantum Efficiency - green (typical) |
41.1 % |
|
EMVA Quantum Efficiency - red (typical) |
6.7 % |
|
Dark Noise (typical) |
6.7 e¯ |
|
Saturation Capacity (typical) |
6.8 ke¯ |
|
Dynamic Range (typical) |
60.0 dB |
|
Signal-to-Noise Ratio (typical) |
38.3 dB |
Camera Data |
|
Interface |
GigE |
|
Pixel Bit Depth |
12 bits |
|
Synchronization |
- hardware trigger
- free-run
- Ethernet connection
|
|
Exposure Control |
- programmable via the camera API
- hardware trigger
|
|
Digital Input |
1 |
|
Digital Output |
1 |
|
Power Supply |
|
|
Power Requirements (typical) |
2.2 W |
|
Power Consumption PoE |
2.7 W |
Housing |
|
Housing Type |
Box |
|
Housing Size (L x W x H) |
42 mm x 29 mm x 29 mm |
|
Lens Mount |
|
|
Operating Temperature |
0 - 50°C |
|
Weight (typical) |
90g |
Conformity |
|
Conformity |
- CE
- RoHS
- GenICam
- GigE Vision
- IP30
- UL
- FCC
- IEEE 802.3af (PoE)
- KC
- EAC
|
