ABX00173 Arduino® UNO™ Q 4GB
- Mã sản phẩm: ABX00173
- Nhà sản xuất: Arduino.cc
- Website hỗ trợ: https://www.proe.vn
3.200.000₫
- Microprocessor: Qualcomm® Dragonwing™ QRB2210
- Microcontroller: Real-time, low-power STM32U585 MCU
- RAM: 4 GB LPDDR4
- Storage: 32 GB eMMC built-in (no SD card required)
- Connectivity: Dual-band Wi-Fi® 5 (2.4/5 GHz), Bluetooth® 5.1
- High-speed headers: Power advanced peripherals – vision, audio, display
- Classic UNO headers: Mount shields to add capabilities
- LED matrix: 8 x 13 LED matrix for visual creation and feedback
- USB-C connector: Power delivery, video output, or connect keyboard, mouse, USB microphones or USB cameras via dongle
- Qwiic connector: Expand easily with Modulino® nodes – no soldering required
UNO Q empowers innovators to turn ideas into real-world solutions. Whether you’re experimenting with IoT, learning robotics, or diving into AI, your next idea starts with Q.
Tech specs
| Microprocessor (MPU) | Qualcomm Dragonwing™ QRB2210: Quad-core Arm® Cortex®-A53 @ 2.0 GHz Adreno GPU 3D graphics accelerator 2x ISP (13 MP + 13 MP or 25 MP) @ 30 fps |
| Microcontroller (MCU) | STM32U585 Arm® Cortex®-M33 up to 160 MHz 2 MB flash memory 786 KB SRAM |
| RAM | 4GB LPDDR4 |
| Power Supply | From USB-C connector 5 V max at 3 A Input Voltage (VIN): 7-24 V |
| Storage | 32GB eMMC |
| USB | 1× USB-C port with host/device role switching, power role switch and video output |
| Connectivity | Wi-Fi® 5 2.4/5GHz with onboard antenna Bluetooth® 5.1 with onboard antenna |
| Interfaces | I2C/I3C SPI PWM CAN UART PSSI GPIO JTAG ADC |
| Video | Video output support via USB-C MIPI DSI pins on JMEDIA header |
| Extra | 4× RGB user-controllable LEDs 8x13 Blue LED Matrix 1x Qwiic connector voltage 3V3, I2C 1x User push-button JCTL: MPU Remote Debug connector |
| Audio | Microphone IN / Headphone OUT / Line OUT on JMISC |
| Dimensions | 68.85 mm x 53.34 mm (UNO form factor) |
| MPU Operating System | Linux Debian OS with upstream support |
| Real-time Operating System | Arduino Core on Zephyr OS |
| Containerization | Docker and Docker Compose support |
| Support Operating Systems for Arduino App Lab | Windows: Windows 10 or later (64-bit) macOS: macOS 11 or later (64-bit) Linux: Ubuntu 22.04 or later, and Debian Trixie (64-bit) |
